Tizian Cut 5.2 Plus milling machine incl. 12x blank changer

Tizian Cut 5.2 Plus milling machine incl. 12x blank changer
Image can differ
  • 523210

Schütz Dental - Tested quality for your safety

Mills nearly all materials that are used in dental technology, such as zirconium dioxide,... more
Product information "Tizian Cut 5.2 Plus milling machine incl. 12x blank changer"

Mills nearly all materials that are used in dental technology, such as zirconium dioxide, non-precious alloys or high-tech resins like e.g. PEEK. Glass ceramics and prefabricated abutments are milled with the wet grinding option. Tizian Cut 5.2 plus has the same features as Tizian Cut 5.2. Tizian Cut 5.2 is optionally available with a 12-fold blank changer.

Possible materials for milling:

  • titanium
  • non-precious alloys
  • zirconium dioxide
  • PMMA resins for temporaries and splints
  • additionally: glass ceramics and lithium disilicate* with a special blank holder
  • wax
  • composite und zirconia-reinforced composites
  • PEEK resins
  • Acetal resins

*available at additional charge

Your advantages

  • Extremely future-proof: due to its integration into the "Complete Digital Workflow"
  • EC-servo motor drive for even higher precision
  • Tilting angle of the axes up to 30° for milling extreme undercuts
  • Integrated CAM-PC with touchscreen
  • Tool changer protected against dust/shavings for a longer service life
  • Compact table-top version that needs little space

Technical Data Tizian Cut 5.2

  • 5 axes, simultaneous milling
  • Automatic tool changer with 12 tool compartments
  • High-frequency shaft, max. power output 2,200 W at 60,000 rpm
  • Wet grinding option
  • PC and integrated touchscreen
  • w/d/h approx. 1058 x 789 x 847 mm
  • Weight approx. 225 kg
