Tizian Cut 5.2 Advanced Plus milling machine

Order number: 525210
Tizian Cut 5.2 Advanced Plus milling machine
Image can differ
Description

The Pro-Series for highest demands

Note

For the purchase of this product please contact our service team

Request offer
Order number: 525210
The Pro-Series for highest demands Designed for the modern requirements in CAD/CAM... more
Product information "Tizian Cut 5.2 Advanced Plus milling machine"

The Pro-Series for highest demands

Designed for the modern requirements in CAD/CAM machining. Benefit from extremely high stability and low-vibration machining due to the new one-piece machine housing made from polymer concrete. What's more, the high-resolution dynamic servomotors with absolute measuring system facilitate an up to 20 % faster processing with optimal precision.

Tizian Cut 5.2 Pro Plus Advanced – The professional solution:

The integrated zero-point clamping system facilitates the use of a multitude of adapter systems, such as glass ceramic adapters or different premilled systems. The machine processes restorations with a milling angle of up to 90 degrees with help of the innovative open blank holder. What's more, the Tizian Cut 5.2 Pro Plus with its fully automated blank loader facilitates the multifarious processing of up to 12 blanks in unmanned operation.

Your benefits:

  • Revolutionary machine base made of polymer concrete for a greater rigidity and consequently, a higher precision
  • Simultaneous five-axis machining
  • Absolute measuring systems in all axes
  • Dry and wet machining
  • Machining of all significant materials in dentistry including metals
  • Working angle of the axes of up to +/- 30 degrees
  • 20-fold tool changer, covered
  • Machining on the face of the blank is an option (B axis in 90 degree position)
  • Jäger high frequency spindle with up to 60,000 rpm
  • Blank loader for up to 12 blanks (different materials)

Technical data

  • Simultaneous five-axis machining
  • Automated tool changer with 20 slots (optional)
  • High frequency spindle, max. output power 240 V, 2.6 kW with 60,000 rpm, 6.5 bar, 100 l/min.
  • Integrated wet machining function
  • Integrated PC and touchscreen
  • W/D/H ca. 1058 x 789 x 847 mm
  • Weight ca. 250 kg

Suited for these materials:

  • Titanium
  • Non-precious alloys
  • Zirconium dioxide
  • PMMA acrylics for temporary restorations and splints
  • Wax
  • Composite and Zirconia reinforced composite
  • PEEK materials
  • Acetal acrylics
  • Polycarbonate
  • With additional blank holder: glass ceramics and lithium disilicate**
  • Prefabricated abutments**

**Optional accessory
